knot knot

Space Pools

Space pools keep a fixed number of identical spaces running from a template. A pool stores a target desired_count and an active flag. The cluster leader reconciles pools every 15 seconds: it replaces dead members, creates new members when the pool is below target, drains method traffic before stopping excess members, and applies a grace period before deleting stopped spaces.

Pools do not include built-in autoscaling. Knot exposes utilization stats and a runtime size API so you can write your own scaler in Scriptling or another external tool.

Port Routing

Pool member spaces expose their HTTP and TCP ports under the pool name rather than the individual space name. For example, if user alice has a pool named search-api with an HTTP port on 8080:

https://alice--search-api--8080.knot.example.com

The proxy resolves the pool name, picks a healthy member via round-robin, and routes the request to it. Drained members (being removed) are skipped automatically. If no healthy member is available, the proxy returns 404.

TCP ports work the same way via the WebSocket proxy endpoint /proxy/spaces/{pool_name}/port/{port}.

Lifecycle

When desired_count is reduced on a running pool, excess spaces go through a multi-sweep transition:

  1. Drain — new JSON-RPC method calls stop routing to the space (15s buffer for in-flight requests to complete).
  2. Stop — the container is stopped.
  3. Grace period — the stopped space survives one extra sweep cycle, allowing it to be restarted if desired_count goes back up.
  4. Delete — the space is permanently removed.

If the pool’s desired_count increases before step 3 completes, the space is undrained and continues running without interruption.

Stopping a pool sets active = false and stops all member spaces without deleting them. Starting a stopped pool starts all members and creates new ones if needed.

Deleting a pool requires it to be stopped first. Member space deletion is initiated (marked as deleting), then the pool definition is tombstoned. The container service completes volume cleanup and finalises space deletion asynchronously.

What Pools Track

Pool utilization is calculated from the latest agent state reports and the method registry:

  • Combined request rate across JSON-RPC methods, HTTP requests, and TCP connections
  • JSON-RPC in-flight method calls
  • Average CPU and memory usage across live members
  • Per-member state and utilization for debugging

Scriptling

Use knot.pool to inspect pools and update their target size:

import knot.pool as pool

info = pool.get("search-pool")
util = info["utilization"]

if util["combined_rps"] > 100:
    pool.set_size("search-pool", info["desired_count"] + 1)

set_size() updates the target count immediately. The sweep loop handles draining, stopping, and deleting excess spaces within 1-2 cycles.

API

The pool API is available to authenticated callers:

  • GET /api/pools
  • POST /api/pools
  • GET /api/pools/{id_or_name}
  • PUT /api/pools/{id_or_name}
  • DELETE /api/pools/{id_or_name}
  • POST /api/pools/{id_or_name}/size
  • POST /api/pools/{id_or_name}/start
  • POST /api/pools/{id_or_name}/stop

Pool operations require Use Space Pools permission.

CLI

knot pool list                          # List your pools
knot pool start <name>                  # Start a stopped pool
knot pool stop <name>                   # Stop a running pool
knot pool set-size <name> <count>       # Change the desired space count
knot pool delete <name> [-y]            # Delete a stopped pool (prompts unless -y)
