Two Factor Authentication

To enhance the security of Knot installations, Knot supports Two-Factor Authentication (2FA) through applications like Google Authenticator, Microsoft Authenticator, and even 1Password.

Enabling 2FA

To enable 2FA, edit the knot.toml configuration file and add the following section:

[server.totp]
enabled = true
issuer = 'Knot'
  • The enabled field must be set to true to activate 2FA.
  • The issuer field can be set to a string to identify your installation (e.g., “Knot”).
  • The optional window field sets how many 30-second time steps either side of the current one are accepted, to allow for clock drift. The default 1 accepts the previous, current and next code.
Config Flag Environment Default
server.totp.enabled --enable-totp KNOT_ENABLE_TOTP false
server.totp.issuer --totp-issuer KNOT_TOTP_ISSUER Knot
server.totp.window --totp-window KNOT_TOTP_WINDOW 1

After making these changes, restart Knot to apply the configuration.

First-Time Login with 2FA

Once 2FA is enabled, the login screen includes an extra Authenticator code field.

  1. On the first login, enter your Email and Password and leave the Authenticator code field blank.
  2. Click Sign In. A new secret is generated and shown with a QR code.
  3. Scan the QR code, or enter the secret by hand, in your authenticator application.
  4. Enter the 6-digit code your authenticator application shows and click Verify and continue.

If the code doesn’t match, check that the secret in your app is the one shown on screen, wait for the next code and try again; the secret stays the same, so you can scan the QR code again. Repeated wrong codes count towards the same rate limit as failed logins and are recorded in the audit log.

You can view the secret again later from your profile page.

Subsequent Logins

For all future logins, complete all three fields:

  • Email
  • Password
  • Authenticator code

If all three fields match, you will be successfully logged into the system.

Resetting the TOTP

If a user loses access to their One Time Password, it can be reset using the command line. Run the following command, replacing <email address> with the email address of the user:

knot admin reset-totp <email address>

When the user next logs in, a new QR code will be generated, allowing them to set up 2FA again.
